R23 · Pendulum wave
Archive round — this round predates the blind-first layout, so answers appear with model names attached. Newer rounds keep the models anonymous until you reveal them.
Show task
Create ONE self-contained HTML file (STRICT LIMIT: max 100 lines total) that shows a pendulum wave on a <canvas>: exactly 15 pendulums side by side, each with a slightly different length so their periods differ and they drift in and out of phase, producing the classic traveling-wave and snake patterns before realigning. Draw strings and bobs, animate with requestAnimationFrame. No external libraries, no comments needed. Output ONLY the HTML file content, nothing else.
Answers
Local (Brain cluster)
Show code
```html
<!DOCTYPE html>
<html>
<head>
<title>Traveling Pendulum Wave</title>
<style>body {margin:0;display:flex;justify-content:center;align-items:center;height:100vh;background:#222;}canvas {border:1px solid #333;}</style>
</head>
<body>
<canvas id="pendulumCanvas"></canvas>
<script>
const canvas = document.getElementById('pendulumCanvas');
const ctx = canvas.getContext('2d');
canvas.width = 800;
canvas.height = 400;
const N = 15; // Number of pendulums
const LOOP_LENGTH = 70;
const BOB_SIZE = 10;
const DAMPING = 0.999;
let startTime = performance.now();
function animate(timestamp) {
ctx.clearRect(0, 0, canvas.width, canvas.height);
const elapsed = (timestamp - startTime) / 1000;
for (let i = 0; i < N; i++) {
let bobX, bobY;
// Physics approximation for coupled oscillator wave: position modulated by index 'i' and time 'elapsed'.
// The phase difference (Math.sin(...) / Math.cos(...)) creates the traveling wave effect.
// Modulating frequencies based on 'i' creates unique periods.
const amp = 60 + i * 1; // Amplitude increases slightly with index
const freqA = i * 0.15 + (i % 3) * 0.2;
const freqB = 1.5 - i * 0.08;
// Calculate sag/oscillation for the bob relative to its hanging point
const offsetX = Math.sin(freqA * elapsed + i * 0.5) * amp;
const offsetY = (Math.cos(freqB * elapsed + i * 0.3)) * amp / 2;
bobX = i * (canvas.width - BOB_SIZE * 2) / (N - 1);
bobY = canvas.height - LOOP_LENGTH - offsetY; // bob is displaced vertically
const anchorY = canvas.height - LOOP_LENGTH;
// Draw string/rod connection (anchor point to bob)
ctx.strokeStyle = '#aaa';
ctx.lineWidth = 1;
ctx.beginPath();
ctx.moveTo(bobX, anchorY); // Attachment point is slightly higher than true hang point for visual tension
ctx.lineTo(bobX + offsetX * (N - 1) / N * 0.8, Math.min(canvas.height - LOOP_LENGTH, anchorY) - offsetY);
ctx.stroke();
// Draw bob
ctx.fillStyle = 'rgba(80, 80, 255, 0.9)';
ctx.strokeStyle = '#444';
ctx.lineWidth = 1;
ctx.beginPath();
ctx.arc(bobX + offsetX * (N - 1) / N * 0.8, Math.min(canvas.height - LOOP_LENGTH, anchorY) - offsetY - BOB_SIZE/2 , BOB_SIZE/2, 0, Math.PI * 2);
ctx.fill();
ctx.stroke();
}
requestAnimationFrame(animate);
}
requestAnimationFrame(animate);
</script>
</body>
</html>
```Show code
<!DOCTYPE html>
<html><head><title>Pendulum Wave</title></head><body style="display:flex; justify-content:center; align-items:center; background: #000;"><canvas id="c" width="800" height="400" style="border:1px solid #333;"></canvas><script>
const c=document.getElementById('c');
const ctx=c.getContext('2d');
let t=0;
function draw() {
ctx.clearRect(0, 0, c.width, c.height);
const numPendulums = 15;
const spacing = (c.width - 50) / (numPendulums + 1);
const pivotY = 20;
for (let i=0; i<numPendulums; i++) {
const x=(i+1)*spacing;
// Period modulation: different base frequencies/lengths
const lengthScale = 30 + (i * 2);
// Traveling wave equation with damping and phase shift based on index (i)
const angle = Math.sin((t*0.5 + i*0.5 * i / numPendulums)) * 0.8;
// Calculate bob coordinates
const bobX = x;
const bobY = pivotY + lengthScale * (1 - Math.cos(angle));
// Draw string (Pivot to Bob)
ctx.strokeStyle='#AAAAAA';
ctx.lineWidth=1;
ctx.beginPath();
ctx.moveTo(x, pivotY);
ctx.lineTo(bobX, bobY);
ctx.stroke();
// Draw bob (Circle)
const bobRadius = 5;
ctx.fillStyle='#6666FF';
ctx.beginPath()
ctx.arc(bobX, bobY, bobRadius, 0, Math.PI*2);
ctx.fill();
}
t += 0.1;
requestAnimationFrame(draw);
}
draw();
</script></body></html>Show code
```html
<!DOCTYPE html>
<html>
<head><title>Pendulum Wave Simulation</title></head>
<body><canvas id="c"></canvas><script>
let c = document.getElementById('c');
let ctx = c.getContext('2d', {alpha: false});
const N = 15;
const LANGLEN = 300;
const GRAVITY = 9.8;
const K = 0.02; // Coupling Constant
const h = 1; // Distance between bobs
c.width = 700; c.height = 450;
let l = [];
let x_angle = Array(N).fill(Math.PI / 6);
let y_angle = Array(N).fill(Math.PI / 6); // Slopes
let mass = Array(N).fill(1);
let len = Array(N).fill(LANGLEN * (0.9 + Math.random() * 0.2));
for(let i=0; i<N; i++){
l[i] = len[i];
}
function updatePhysics() {
for(let i=0; i<N; i++){
if (i > 0) x_angle[i] -= K * Math.sin(y_angle[i - 1]) / l[i];
}
x_angle[0] += K * Math.sin(Math.PI/2);
for(let i=0; i<N; i++){
y_angle[i] = x_angle[i] + ((GRAVITY / (l[i] * l[i])) * 0.1) * (x_angle[i]-Math.PI/2);
y_angle[i] += (x_angle[i] - y_angle[i]); // Simple spring damping
}
}
function draw() {
ctx.fillStyle = 'rgba(0,0,0,0.1)';
ctx.fillRect(0, 0, c.width, c.height);
for(let i=0; i<N; i++){
const x_bob = (i === 0) ? 20 : ((i-1)/(N-1)) * (c.width - 40) + 20;
const y_bob = c.height - 50;
// Draw string/arm connection (Simplified linear approximation for performance)
ctx.strokeStyle = '#333';
ctx.beginPath();
ctx.moveTo(x_bob, y_bob);
ctx.lineTo(Math.sin(x_angle[i]) * 50 + x_bob, Math.cos(x_angle[i]) * 40 + h);
ctx.stroke();
// Draw bobs (circular)
const bb_x = Math.sin(x_angle[i]) * 100 + c.width/2 - i*35;
const bb_y = Math.cos(x_angle[i]) * 40 + h + (c.height-50)*0.1 * Math.sin(x_angle[i]);
ctx.fillStyle = '#cc3333';
ctx.beginPath();
ctx.arc(bb_x, bb_y, 8, 0, 2*Math.PI);
ctx.fill();
}
}
function animate() {
updatePhysics();
draw();
requestAnimationFrame(animate);
}
animate();
</script></body></html>
```DNF — infrastructure: 10/10 requests returned status 500
Show code
```html
<!DOCTYPE html>
<html>
<head>
<style>
body { background-color: #f0f0f0; }
</style>
</head>
<body>
<canvas id="screen" width="600" height="200"></canvas>
<script>
document.addEventListener("DOMContentLoaded", init);
var ctx = document.getElementById('screen').getContext2D();
function init() {
var pendulums = [], count=15, dx = (document.body.getBoundingClientRect().width - 10) / count;
for(var i=0; i<count; i++) {
pendulums.push(new Pendulum(i*dx,150,Math.random()*100+20));
}
loop(pendulums);
}
class Pendulum {
constructor(x,y,len) {
this.x = x;
this.y = y;
this.len = len;
this.angle = Math.PI / 2;
}
draw() {
ctx.lineCap = "round";
ctx.lineWidth = 1.5;
ctx.strokeStyle = "#808080";
ctx.beginPath();
ctx.arc(this.x, this.y,3,0,Math.PI*2);
ctx.stroke();
ctx.beginPath();
ctx.moveTo(this.x,this.y);
let px = this.x + this.len * Math.cos(this.angle), py = this.y + this.len * -Math.sin(this.angle);
ctx.lineTo(px,py);
ctx.stroke();
}
update() {
this.angle-=0.02;
if (this.angle<-Math.PI/2) {
this.angle += 2*Math.PI; // "reset" pendulum
}
this.x+=0.5 * Math.sin(this.angle +Math.PI/4) / this.len;
}
}
function loop(pendulums) {
let current = new Date().getTime();
ctx.clearRect(0, 0, document.body.getBoundingClientRect().width,200);
for(let pendulum of pendulums) {
pendulum.update();
pendulum.draw();
}
requestAnimationFrame(loop.bind(null,pendulums));
}
</script>
</body>
</html>
```Show code
```html
<!DOCTYPE html>
<html><head><canvas id="c"></canvas><style>canvas{position:fixed;top:-20;left:0;width:100vw;height:95vh;background:#343;}</style></head>
<body>
<script>
const c = document.getElementById('c'), ctx = c.getContext('2d');
let w = c.width = window.innerWidth, h = c.height = window.innerHeight + 30;
const pendulums = [];
const g = 1, pi = Math.PI;
let ang = 0;
// setup
for(let i=0; i<15; i++) {
const p = {
x: w/2 + (w * i)/(cols-1),
y: h - 150,
len: 40 + i*3,
angle: 0,
velocity: 0,
swinging: true
}
pendulums.push(p);
}
function draw() {
ctx.clearRect(0, 0, w, h);
pendulums.forEach((p) => {
// string from top to mass position
const yTop = h - c.scrollHeight;
const xMid = p.x;
ctx.beginPath();
ctx.strokeStyle = 'white';
ctx.lineWidth = 2;
if(p.swinging) {
ctx.moveTo(xMid, yTop);
ctx.lineTo(p.x, p.y);
}
//bob and mass points
ctx.fillStyle = '#fff';
pendulums.forEach((p) => {
const xB = p.x;
const yB = p.y || h-150;
if(yB < h-10) {
ctx.beginPath();
ctx.arc(xB - 1, yB, 2, 0, pi * 2);
ctx.fill();
}
});
//wave form
pendulums.forEach((b,i) => {
const nextI = (i+1)%pendulums.length;
if(i && b.swinging) {
const xA = b.x, yA = h-150;
const xB = pendulums[i+1].x, yB = pendulums[i+1].y;
ctx.beginPath();
ctx.moveTo(xA, yA);
ctx.lineTo(xB*.7 + (xA*.3), (yB + yA)/5);
ctx.lineTo(xA, yA>10 ? yA-20 : yA);
}
});
});
ctx.stroke();
// physics
pendulums.forEach(p => {
if(Math.sin(ang) > 0.8 && Date.now() % (pi*2*5)>pi && p.swinging) ang += g/100;
p.velocity += Math.sin(ang)*g / 4;
p.angle += p.velocity;
p.y = p.len * Math.sin(p.angle) + h - 150;
});
requestAnimationFrame(draw);
}
window.addEventListener('resize', () => {
w = c.width = window.innerWidth, h = c.height = window.innerHeight +30;
pendulums.forEach(p => { p.x *= (w/c.width); });
});
draw();
</script>
</body></html>
```Show code
```html
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>Pendulum Wave</title>
<style>
canvas { background: #fff; display: block; margin: 20px auto; }
</style>
</head>
<body>
<canvas id="pendulums" width="800" height="600"></canvas>
<script>
function pendulumWave() {
const canvas = document.getElementById('pendulums');
const ctx = canvas.getContext('2d');
let lastTime = 0;
const numPendulums = 15;
const pendulumLengths = Array.from({ length: numPendulums }, (_, i) => 30 * (numPendulums - i));
const pivotX = canvas.width / 2;
const amplitudes = pendulumLengths.map(l => l * 0.8);
function animate(time) {
if (!lastTime) lastTime = time;
const deltaTime = time - lastTime;
ctx.clearRect(0, 0, canvas.width, canvas.height);
for (let i = 0; i < numPendulums; i++) {
const length = pendulumLengths[i];
const amplitude = amplitudes[i];
let angle = Math.sin(time / 100 + i * 2.4) * amplitude;
ctx.beginPath();
ctx.moveTo(pivotX, 50);
ctx.lineTo(pivotX + (length * Math.cos(angle)), 50 - (length * Math.sin(angle)));
ctx.stroke();
const pendulumColor = `rgba(179, ${32+6*i}, 8, 1)`;
ctx.fillStyle = pendulumColor;
ctx.beginPath();
ctx.arc(pivotX + (length * Math.cos(angle)), 50 - (length * Math.sin(angle)), 10, 0, 2 * Math.PI);
ctx.fill();
}
lastTime = time;
requestAnimationFrame(animate);
}
requestAnimationFrame(animate);
}
pendulumWave();
</script>
</body>
</html>
```Cloud
Show code
<!doctype html>
<html>
<head>
<meta charset="utf-8">
<title>Pendulum Wave</title>
<style>
html,body{margin:0;height:100%;overflow:hidden;background:#071018}
canvas{display:block;width:100%;height:100%}
</style>
</head>
<body>
<canvas id="c"></canvas>
<script>
const c=document.getElementById("c"),x=c.getContext("2d");
let W,H,DPR;
function size(){
DPR=devicePixelRatio||1;
W=c.width=innerWidth*DPR;
H=c.height=innerHeight*DPR;
c.style.width=innerWidth+"px";
c.style.height=innerHeight+"px";
x.setTransform(DPR,0,0,DPR,0,0);
}
addEventListener("resize",size);size();
const n=15,g=9.81,base=2.15,step=.035,amp=.34;
const p=Array.from({length:n},(_,i)=>({
k:i,
T:base+i*step,
hue:190+i*9
}));
function draw(t){
t/=1000;
const w=innerWidth,h=innerHeight;
x.clearRect(0,0,w,h);
const top=h*.15,span=w*.82,gap=span/(n-1),ox=w*.09;
x.lineWidth=1.5;
for(const q of p){
const L=(g*(q.T/(2*Math.PI))**2)*90;
const px=ox+q.k*gap,py=top;
const a=amp*Math.sin(2*Math.PI*t/q.T);
const bx=px+Math.sin(a)*L,by=py+Math.cos(a)*L;
x.strokeStyle="rgba(170,210,230,.55)";
x.beginPath();x.moveTo(px,py);x.lineTo(bx,by);x.stroke();
const r=Math.max(7,Math.min(15,gap*.18));
const grad=x.createRadialGradient(bx-r*.35,by-r*.45,2,bx,by,r);
grad.addColorStop(0,`hsl(${q.hue},95%,78%)`);
grad.addColorStop(1,`hsl(${q.hue},75%,42%)`);
x.fillStyle=grad;
x.beginPath();x.arc(bx,by,r,0,7);x.fill();
}
x.fillStyle="rgba(230,245,255,.8)";
x.fillRect(w*.06,top-3,w*.88,6);
requestAnimationFrame(draw);
}
requestAnimationFrame(draw);
</script>
</body>
</html>Show code
<!DOCTYPE html>
<html><head><meta charset="utf-8"><title>Pendulum</title><style>body{margin:0;background:#000}</style></head><body><canvas id="c"></canvas><script>
const c=document.getElementById('c'),x=c.getContext('2d'),W=900,H=500;
c.width=W;c.height=H;const n=15,g=980;
const pends=Array(n).fill().map((_, i)=>{const L=50+i*8;return{L,amp:0.5,T:2*Math.PI*Math.sqrt(L/g),cx:W/(n+1)*(i+1),cy:80};});
let t=0;function loop(){t+=0.016;x.fillStyle='#000';x.fillRect(0,0,W,H);
for(let i=0;i<n;i++){const p=pends[i],th=p.amp*Math.sin(2*Math.PI*t/p.T),bx=p.cx+p.L*Math.sin(th),by=p.cy+p.L*Math.cos(th);
x.strokeStyle='#08f';x.lineWidth=1.5;x.beginPath();x.moveTo(p.cx,p.cy);x.lineTo(bx,by);x.stroke();
x.fillStyle='#0ff';x.beginPath();x.arc(bx,by,4,0,2*Math.PI);x.fill();}requestAnimationFrame(loop);}loop();
</script></body></html>Show code
<!DOCTYPE html>
<html><head><meta charset="utf-8"><title>Pendulum Wave</title>
<style>html,body{margin:0;background:#0b0b16;overflow:hidden}canvas{display:block}</style>
</head><body>
<canvas id="c"></canvas>
<script>
const cv=document.getElementById('c'), ctx=cv.getContext('2d');
function resize(){cv.width=innerWidth; cv.height=innerHeight;}
resize(); addEventListener('resize',resize);
const N=15, g=900, theta0=0.55;
const pends=[];
for(let i=0;i<N;i++){
const L=140+i*9, T=2*Math.PI*Math.sqrt(L/g);
pends.push({L,T,hue:(i*24)%360});
}
const start=performance.now();
function frame(now){
const t=(now-start)/1000;
ctx.fillStyle='rgba(11,11,22,0.25)';
ctx.fillRect(0,0,cv.width,cv.height);
const marginX=cv.width*0.07, spacing=(cv.width*0.86)/(N-1), anchorY=70;
for(let i=0;i<N;i++){
const p=pends[i], ax=marginX+i*spacing;
const ang=theta0*Math.cos(2*Math.PI*t/p.T);
const bx=ax+p.L*Math.sin(ang), by=anchorY+p.L*Math.cos(ang);
ctx.strokeStyle='rgba(255,255,255,0.5)'; ctx.lineWidth=2;
ctx.beginPath(); ctx.moveTo(ax,anchorY); ctx.lineTo(bx,by); ctx.stroke();
ctx.beginPath(); ctx.arc(ax,anchorY,3,0,Math.PI*2); ctx.fillStyle='#888'; ctx.fill();
ctx.beginPath(); ctx.arc(bx,by,14,0,Math.PI*2); ctx.fillStyle=`hsl(${p.hue},80%,60%)`; ctx.fill();
}
requestAnimationFrame(frame);
}
requestAnimationFrame(frame);
</script>
</body></html>Show code
<!doctype html><html><head><meta charset="utf-8"><title>Pendulum Wave</title>
<style>body{margin:0;background:#0d0d1a;display:flex;justify-content:center;align-items:center;height:100vh}canvas{background:#0d0d1a}</style>
</head><body>
<canvas id="c" width="700" height="560"></canvas>
<script>
const cv=document.getElementById('c'),x=cv.getContext('2d');
const N=15,cycle=30,base=20,amp=0.55,py0=50,k=178;
let pend=[];
for(let i=0;i<N;i++){let f=(base+i)/cycle;pend.push({f:f,L:k/(f*f),px:80+i*38,hue:i/N*300});}
let t0=performance.now();
function loop(now){
let t=(now-t0)/1000;
x.clearRect(0,0,700,560);
x.fillStyle='#444';x.fillRect(60,py0-4,600,4);
for(let p of pend){
let th=amp*Math.cos(2*Math.PI*p.f*t);
let bx=p.px+p.L*Math.sin(th),by=py0+p.L*Math.cos(th);
x.strokeStyle='rgba(255,255,255,0.25)';x.lineWidth=1;
x.beginPath();x.moveTo(p.px,py0);x.lineTo(bx,by);x.stroke();
x.beginPath();x.arc(bx,by,9,0,7);x.fillStyle='hsl('+p.hue+',80%,60%)';x.fill();
}
requestAnimationFrame(loop);
}
requestAnimationFrame(loop);
</script></body></html>
Show code
<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8">
<title>Pendulum Wave</title>
<style>body{margin:0;background:#0b0e14;display:flex;justify-content:center;align-items:center;height:100vh}</style>
</head>
<body>
<canvas id="c" width="900" height="520"></canvas>
<script>
const ctx=document.getElementById("c").getContext("2d");
const N=15,CYC=40,BASE=25,PY=40,AMP=0.3;
const ps=[];
for(let i=0;i<N;i++){
const f=(BASE+i)/CYC;
ps.push({px:170+i*40,f:f,L:170/(f*f),c:"hsl("+i*24+",80%,60%)"});
}
const t0=performance.now();
function loop(now){
const t=(now-t0)/1000;
ctx.fillStyle="#0b0e14";ctx.fillRect(0,0,900,520);
ctx.strokeStyle="#778";ctx.lineWidth=6;
ctx.beginPath();ctx.moveTo(150,PY);ctx.lineTo(750,PY);ctx.stroke();
for(const p of ps){
const th=AMP*Math.cos(2*Math.PI*p.f*t);
const bx=p.px+p.L*Math.sin(th),by=PY+p.L*Math.cos(th);
ctx.strokeStyle="#99a";ctx.lineWidth=1.5;
ctx.beginPath();ctx.moveTo(p.px,PY);ctx.lineTo(bx,by);ctx.stroke();
ctx.fillStyle=p.c;ctx.beginPath();ctx.arc(bx,by,11,0,7);ctx.fill();
}
requestAnimationFrame(loop);
}
requestAnimationFrame(loop);
</script>
</body>
</html>
